DARC Virtual

The ultimate software console.

Purchase with Confidence.

What you need to get started

Getting started with DARC Virtual is extremely simple. You only need two components:



(1) Audio Hardware - You need to connect your audio sources, such as microphones, headphones, phone systems, automation, etc... This can be done using a ASIO USB Audio Interface, such as the Behringer UMC1820. This gives you 10 mono audio inputs and outputs. To expand further, you can get the Behringer ADA8200.



(2) DARC Virtual software - Then all you need is the DARC Virtual console software ran on a Windows PC (not included). This software is designed to recognize ASIO hardware devices on your PC, and then gives you the ability to control any of these audio inputs & outputs.



DARC Surface (Optional) - The DARC Surface is perfect for those who would like a physical interface to control the DARC Virtual.  Learn more.







Some possible configurations could include:

Starter Bundle - $699

10 mono inputs /  12 mono outputs



What's included:

▪ DARC Virtual 4 Console software license ($400 Value)

▪ Behringer UMC1820 ($299 Value) *Prices may change at any time without notice.

▪ Windows PC not included

INPUTS - 10 Mono inputs

▪ Qty 8 - XLR or 1/4 TRS connectors.

▪ 8 Midas designed mic preamps, which include +48V phantom power for condenser microphones.

▪ Independent channel audio level adjust.

▪ Inputs 9 & 10 are SPDIF digital connectors. May require A/D converter.



OUTPUTS - 12 Mono outputs + Headphone out

▪ Qty 10 - 1/4 TRS connectors.

▪ Outputs include:

▪ Program

▪ Audition

▪ Utility

▪ Mix- (External Phone Hybrid required)

▪ Cue

▪ Monitor (SPDIF output may require D/A converter)

▪ 1/4 Headphone output built into UMC1820. Includes volume adjust, and select between Program and Audition mixes.

▪ Outputs 11 & 12 are SPDIF digital connectors, which are assigned to the Monitor output. May require D/A converter.

Click here to learn more about the UMC1820

Pro Bundle - $1,328

18 mono inputs /  20 mono outputs



What's included:

▪ DARC Virtual 8 Console software license ($800 Value)

▪ Behringer UMC1820  ($299 Value) *Prices may change at any time without notice.

▪ Behringer ADA8200  ($229 Value)  *Prices may change at any time without notice.

▪ Windows PC not included

INPUTS - 18 Mono inputs

▪ Qty 8 XLR or 1/4 TRS connectors.

▪ Qty 8 XLR connectors.

▪ 16 Midas designed mic preamps, which include +48V phantom power for condenser microphones.

▪ Independent channel audio level adjust.

▪ Inputs 9 & 10 are SPDIF digital connectors. May require A/D converter.



OUTPUTS - 20 Mono outputs

▪ Qty 10 - 1/4 TRS connectors.

▪ Outputs include:

▪ Program

▪ Audition

▪ Utility

▪ Mix- (qty 6) (External Phone Hybrid required)

▪ Cue

▪ Monitor (SPDIF output may require D/A converter)

▪ Headphone

▪ 1/4 Headphone out built into UMC1820. Includes volume adjust, and select between Program and Audition mixes.

▪ 2nd Headphone output with software volume control.

▪ Outputs 11 & 12 are SPDIF digital connectors, which are assigned to the Monitor output. May require D/A converter.



Click here to learn more about the UMC1820

Click here to learn more about the ADA8200

Accessories

APEX-Live is the perfect companion to DARC Virtual for creating dynamic and powerful podcasts. APEX Live is the ultimate live assist software for any Podcast, Internet or Broadcast radio station. It is flexible, with customizable user interfaces; and powerful with numerous features. Use it in tandem with DARC Virtual, or as a stand alone software. And even better, it is FREE with DARC Virtual.



Learn more.

Sound pads, playlists,

custom user profiles and more.

APEX Live gives you unlimited customizable sound pads. Play, loop and fade any track. Whether it is a music bed, effect or audio clip. Customize your colors and arrange your sound pads the way you want it.



You may also create playlists and save for playback. Allowing you to organize your show for easy operation.



With APEX-Live, you can create unlimited user profiles. Each with their own customizable screens and arrangements. One user may prefer

more sound pads, while others choose to view all screens. Setup your screens your way, and switch between profiles at any time. Choose from Sound Pads, Playlist, Volume Control, File Info, Preview Player and more.

Configured PC

$1,099

Purchase a fully configured Dell Optiplex Micro from us. This PC will be ready for use out of the box to work with the DARC Virtual Console software.



For the most effective support experience, we recommend the purchase of a configured PC from us.



Headphone amp

Behringer MicroAMP HA400 4-channel

$29.75 *price may change at any time.

The bundles above include 1 headphone output, so if you are needing more, this option is the way to go. The Behringer HA400 gives you 4 headphone outputs to go to your guests. Physical volume control is ideal, so that you may give your guests an easy way to adjust their own levels. Learn more.

Phone Hybrid

JK Audio Inkeeper PBX

$540 *price may change at any time.

For the highest quality, connect your DARC Virtual system to a landline phone hybrid. The Innkeeper PBX easily converts your multi-line PBX type telephone system into a professional, affordable talk show console. Learn more.

ADC & DAC adapters

$17 to $21 *price may change at any time.

The DARC Virtual output is assigned to your Monitor speakers. If your speakers only have an analog input, you will need to purchase the DAC. Here is one such DAC that you may use. Learn more.

If you are wanting to bring in an analog input, you will want to use an ADC. Here is one such ADC that you may use. Learn more.
